Coming soon to rrdyn.comDemos & individual surveys available now

Geophysical & earthwork software, built for the field.

Red Rocks Dynamics builds browser-based tools that carry a project from survey layout to finished report: survey grids and elevations, TRN terrain files, report-ready resistivity images, and well pad cut & fill estimates — with nothing to install.

Explore the tools Call (469) 245-9044
  • No software to install
  • Works on laptops & tablets
  • Talk to a real person

What’s available now and what’s coming soon

Available now

  • Live demosCall to see any tool in action
  • Individual surveysCall to request one for your project

Coming soon

  • Online suiteAll four tools, right here on rrdyn.com
  • Commercial licensesFor your company and field crews

The Suite

Four focused tools. One clear path from survey to site.

Each tool does one job and does it well. Use them on their own, or together as a complete workflow — from the first survey stake to the final cut & fill report.

  1. 01 Topography Generator Lay out survey grids on satellite imagery and capture an elevation for every point. See the details
  2. 02 Terrain File Generator Turn elevation spreadsheets into clean TRN terrain files for resistivity inversion. See the details
  3. 03 Image Processor Auto-crop a whole batch of section images and build a print-ready PDF sheet. See the details
  4. 04 Cut & Fill Estimator Estimate well pad earthwork with balanced cut and fill and a client-ready report. See the details
Survey grid laid out over a topographic mapA six-line by fifteen-point survey grid set from four corner points inside a KMZ boundary, with one point showing its coordinates and elevation.1234KMZ boundarySURVEY GRID6 lines × 15 points5.00 m inline · 10.00 m crosslinePOINT 56 · LINE 432.42071208, −104.22883145Elevation 951.4172 mN025 m
Sample survey grid: six lines of fifteen points, set from four corners inside a KMZ boundary.
01

Survey planning

Coming soon online

Topography Generator

Lay out a survey grid on satellite imagery — and capture an elevation for every point.

Load your KMZ or KML boundary, click the corners of the survey area, and set the number of lines, points per line and spacing. The Topography Generator places a precise, numbered grid across the site — even on skewed or irregular sites — then looks up the elevation of every point in fast, automatic batches.

  • Up to 224 points per line and 100 lines per grid
  • Four-corner layout that fits the grid to your site, or exact spacing you set
  • Freeform mode for up to 100 spot points, placed with a click
  • Jump to any address, decimal coordinates or degrees-minutes-seconds
  • Optional weather readout for the survey area
Exports KML for Google Earth Elevation CSV
Request a demo of the Topography Generator
Electrode profile and the TRN terrain file written from itA 28-electrode resistivity line drawn over its ground profile, the first lines of the matching TRN terrain file, and a list of terrain files ready to download as a ZIP.LINE 1 · 28 ELECTRODES · 5 m SPACING+0.0+1.0+2.00255075100125 mterrain_1.trnTRN123456789; TRN FileUnits=meters 5;x, Elevation0,1.00005,0.300710,0.429815,0.389020,0.3792READY TO DOWNLOADterrain_1.trn0.31 KBterrain_2.trn0.31 KBterrain_3.trn0.31 KBterrain_4.trn0.31 KBterrain_files.zip
Sample output: a 28-electrode line and the TRN terrain file written from it.
02

Resistivity processing

Coming soon online

Terrain File Generator

Turn a spreadsheet of elevations into clean TRN terrain files — in seconds.

Import a CSV or Excel file, or paste your elevations straight in. Enter the electrode count and spacing, and the Terrain File Generator writes a correctly formatted TRN file for every survey line — so topographic correction in your resistivity inversions never holds up the report.

  • 1 to 224 electrodes per line, at spacings from 0.25 m to 100 m
  • Multi-line spreadsheets split into separate files automatically
  • Correct decimal places for whole, half and quarter-meter spacing
  • Optional terrain header, switched on or off with one click
  • Manual entry for quick, single-line jobs
Exports TRN terrain files ZIP of every line
Request a demo of the Terrain File Generator
Resistivity section image cropped automatically and placed on a PDF contact sheetAn exported inversion image with excess whitespace, the tightly cropped result, a list of cropped files, and a PDF page holding 21 labeled images.Line 03 · Inverted resistivity section101001000 Ω·m12 images selectedBEFORE1920 × 1080AFTER1484 × 612Line_01_cropped.png412 KBLine_02_cropped.png398 KBLine_03_cropped.png405 KBLine_04_cropped.png421 KB+ 8 more21PER PAGEPDF + ZIP
Sample output: an inversion image before and after auto-cropping, with the PDF contact sheet.
03

Reporting

Coming soon online

Image Processor

Crop a whole survey’s worth of images in one pass — and get a print-ready PDF.

Select every inversion image from a job at once. The Image Processor finds each plot, trims away excess whitespace and borders while keeping titles intact, and sorts the results by name. Download images one by one, or export everything as a ZIP with a high-resolution PDF contact sheet for your report appendix.

  • Batch processing — select dozens of images at once
  • Automatic trimming of whitespace and borders
  • Smart name sorting, so Line 2 comes before Line 10
  • PDF contact sheet with 21 labeled images per page
  • Lossless PNG output — every pixel preserved
Exports Cropped PNG images PDF contact sheet ZIP bundle
Request a demo of the Image Processor
Well pad plan view, balanced cut and fill volumes, and cross-section A–A′A pad outline with its grading limit and three section lines on a contour map, a volume table showing cut and fill nearly balanced, and a profile of natural ground against the flat pad and side slopes with cut and fill areas shaded.AA′BB′CC′NPROPOSED PAD ELEVATION3,247.38′CUT6,482.15CU. YD.FILL6,479.88CU. YD.NET2.27CU. YD.Pad area4.12 acSide slope3.0H : 1VRelief7.8′Points surveyed5,982SECTION A–A′3,2403,2453,2503,255PAD EL. 3,247.38′0+001+002+003+004+005+006+00CutFillGroundDesign
Sample report data: plan view, balanced volumes and cross-section A–A′.
04

Pad construction

Coming soon online

Cut & Fill Estimator

Outline a pad. Get balanced cut and fill volumes and a client-ready report.

Upload a KML or KMZ pad boundary, or trace one freehand over satellite imagery — with a mouse, or an Apple Pencil on iPad. The Cut & Fill Estimator samples the terrain, models the pad and its side slopes on a 2.5-foot grid, and finds the pad elevation where cut and fill balance. Fine-tune the result, review the cross-sections, and export a one-page report.

  • Automatic balanced pad elevation, adjustable in 0.25 ft steps
  • Side slopes matched to the ground — 3H:1V standard, flatter for deep grading
  • Three adjustable cross-sections: A–A′, B–B′ and C–C′
  • Cut, fill and net volumes in cubic yards, plus pad area and relief
  • Report location block — coordinates and county — filled in for you
Exports PDF cut & fill report Elevation CSV Graded KMZ
Request a demo of the Cut & Fill Estimator

How it works

From first stake to final report.

Here’s how a typical project moves through the suite. Start wherever your job starts — every tool also works on its own.

  1. Step 1: Plan the survey

    Lay out survey lines on the map, number every point, and export elevations.

    Topography Generator

  2. Step 2: Prepare terrain files

    Turn elevations into TRN files so every inversion accounts for the lay of the land.

    Terrain File Generator

  3. Step 3: Build the report

    Crop the inversion images and lay them out on a clean, print-ready PDF sheet.

    Image Processor

  4. Step 4: Plan the pad

    Balance cut and fill, review the cross-sections, and hand off a one-page report.

    Cut & Fill Estimator

Precision where it counts.

The numbers behind the suite — built for real survey lines, real pads and real reports.

  • 224points per survey line
  • 100lines in a single survey grid
  • 2.5ftcut & fill modeling grid
  • 8decimal places on every coordinate

Why Red Rocks

Built for the people who do the work.

Field software should be as dependable as the rest of your gear. Every tool in the suite is built around clear controls, trustworthy numbers, and files that fit the way you already work.

Request a demo

  • Nothing to install

    Every tool opens in a modern web browser. No downloads, no administrator rights, no waiting on IT.

  • Clear, simple controls

    Plain-language labels, large buttons and built-in Quick Tips on every screen, so new crew members pick it up fast.

  • Your files stay yours

    Spreadsheets, images and boundaries are processed on your own computer or tablet — never stored on our servers.

  • Standard file formats

    KML/KMZ, CSV, Excel, TRN, PNG and PDF — files that open in Google Earth, spreadsheets and the software you already use.

  • In the office or the field

    Layouts adapt to laptops and tablets, and the Cut & Fill Estimator lets you trace a pad boundary with an Apple Pencil.

  • Numbers you can stand behind

    Coordinates to eight decimal places, elevations to four, and earthwork modeled on a 2.5-foot grid.

Made for teams that read the ground and move the dirt.

  • Geophysical survey crews
  • Oil & gas operators
  • Pad construction contractors
  • Environmental & geotechnical consultants
  • Civil engineers & estimators

FAQ

Questions, answered.

Don’t see your question here? Call (469) 245-9044 and ask us directly.

When will the suite be available online?

Soon. All four tools are coming to rrdyn.com. Until the suite launches, call or text (469) 245-9044 to request a demo or an individual survey.

Will commercial licenses be available?

Yes. Commercial licenses will be available soon. In the meantime, call (469) 245-9044 with questions or to request a demo.

Can I see the software before it launches?

Yes. Call (469) 245-9044 to schedule a live demo of any tool in the suite.

Can I request a survey before the suite launches?

Yes. Call (469) 245-9044 to request an individual survey for your project. We’ll talk through your site and what you need.

Will I need to install anything?

No. Once the suite launches, every tool runs right in a modern web browser such as Chrome, Edge, Safari or Firefox. There’s nothing to download, and no administrator rights are needed.

What devices can I use?

Windows and Mac computers, plus tablets such as the iPad. The Cut & Fill Estimator even lets you trace a pad boundary with an Apple Pencil. For large surveys, a laptop or desktop gives you the most room to work.

Do I need an internet connection?

Yes. The map-based tools use live satellite imagery and elevation data, so they need a connection while you work. The Terrain File Generator and Image Processor are lightweight and run well on an ordinary connection.

Are my files uploaded anywhere?

No. Your spreadsheets, images and boundaries are processed right on your own device and are never stored on our servers. The map-based tools send only the locations they need to retrieve imagery and elevations.

Which file types does the suite work with?

It reads KML and KMZ boundaries, CSV and Excel spreadsheets, and common image formats such as PNG and JPG. It creates KML and KMZ files for Google Earth, CSV spreadsheets, TRN terrain files, PNG images, PDF reports and ZIP bundles.

Can you add a feature my team needs?

Tell us about it. Give us a call and walk us through your workflow — we’re always looking for ways to make the tools more useful in the field.
